Cole-Parmer® 自洁pH电极,CPVC外壳,10英尺的电缆,BNC
平板电极表面设计防止防止了固体的附着
这些特殊的双节电极能够应用于复杂的PH测量和ORP应用。光滑的外表不会附着固体悬浮物流
体通过时实现了电极的自清洁功能,延长电极的使用寿命,提高了性能。环形路口减少了引
用单元格的污染。
选择一个CPVC材料的(最高温度80℃),耐化学腐蚀的Ryton®外壳(最高温度100°C)。这
两种类型都有氟橡胶® O型环,外罩式玻璃泡和一个10英尺的屏蔽电缆,可用于在压力高达
100磅的环境下保护电极。内置的ATC电阻和BNC连接器匹配各种器件和控制器。电极安装在三
通管件-3/4“NTP”(M)线程和1-3/4“插入深度。注: 100Ω铂电阻温度传感器的ATC电阻
符合DIN曲线43760。
Cole-Parmer® self-cleaning pH electrode, CPVC housing, 10-ft cable, BNC
Flat electrode surface prevents buildup of solids
Use these unique double-junction electrodes in your most difficult pH and ORP
applications. Flat surface does not collect suspended solids—fluid flow across
the electrode provides a cleaning action that extends electrode life and improves
performance. Annular junction reduces reference cell fouling.
Choose either a CPVC housing (max temp 80°C) or chemical resistant Ryton®
housing (max temp 100°C). Both types have Viton® O-ring to hold glass bulb in
place and a 10-ft shielded cable and can be used at pressure up to 100 psi.
Built-in ATC elements and BNC connectors match a variety of meters and
controllers. Install electrodes in tee fittings—3/4″ NPT(M) thread and 1-3/4″
insertion depth.
Note: 100 Ω Pt RTD ATC elements conform to DIN curve 43760.
产品规格
|
产品类型
|
行中
|
ATC电阻
|
无
|
最高温度
|
176°F(80°C)
|
ATC接头
|
NA
|
连接点
|
双击
|
外壳
|
CPVC
|
过程连接
|
3/4“NPT(M)
|
电缆长度
|
10英尺
|
连接器
|
BNC
|
最大压力
|
100磅
|
制造商编号
|
1922757-010B
|
品牌
|
Cole-Parmer
|
