Cole-Parmer 500电导率/ TDS /温度1/4-DIN控制器
Cole-Parmer 500 Cond/TDS/Temperature 1/4-DIN Controller
Isolated and reversible 4 to 20 mA output allow for proportional output!
Backlight, graphic LCD for clear measurement display
Convenient one point calibration
Password protected ensures security of system
Conductivity range 0.000 to 300,000µS
Accepts probes with 0.01, 0.1, 1.0, 10 cell constants in 2- or 4-wire designs
RS-485 output for remote access allows multiple unit control from your computer
Cole-Parmer online controllers offer features found in more expensive models. Backlight, graphic LCD simultaneously displays measurement, temperature, cell constant, temperature coefficient, relay status, and transmitter current output. Calibration data is stored in memory; making the unit ready for measurement. User selectable cell constants, reference temperature and temperature coefficients; and automatic temperature compensation ensure measurement accuracy. Password protection, RS-485 for remote access, and the isolated and reversible 4 to 20 mA output offer extended data options with security.
Compatable with a 10K thermistor conductivity cells.Cond 500 (05802-06) controller has one isolated and reversible 4 to 20 mA output and three sets of programmable on/off relays: two for conductivity and one for temperature–ideal for high/low control to activate an alarm, a pump, or another device.
|
产品规格
|
|
产品类型
|
调节器
|
|
范围（毫克/升（PPM））
|
0.000 to 150,000 ppt
|
|
范围（温度）
|
-10℃〜120℃
|
|
精确度（毫克/升（ppm））
|
±0.5％+ 1位数
|
|
准确度（温度）
|
±0.3°C
|
|
分辨率（mg / L（PPM））
|
0.001 ppm; 0.1 ppt
|
|
分辨率（温度）
|
0.1°C
|
|
输出（电流）
|
隔离的4至20 mA
|
|
输出（继电器）
|
三SPDT 继电器
|
|
尺寸
|
3/4“×3/4”×5 13/16“
|
|
控制类型
|
开/关
|
|
密码保护
|
是
|
|
显示
|
图形LCD
|
|
功率
|
115至230 VAC，50/60赫兹
|
|
外壳
|
1/4-DIN
|
|
符合CE认证
|
是
|
|
品牌
|
Cole-Parmer
|
|
Specifications
|
|
Product Type
|
Controller
|
|
Range (mg/L (ppm))
|
0.000 to 150,000 ppt
|
|
Range (Temperature)
|
-10 to 120°C
|
|
Accuracy (mg/L (ppm))
|
±0.5% + 1 digit
|
|
Accuracy (Temperature)
|
±0.3°C
|
|
Resolution (mg/L (ppm))
|
0.001 ppm; 0.1 ppt
|
|
Resolution (Temperature)
|
0.1 °C
|
|
Output (Current)
|
Isolated 4 to 20 mA
|
|
Output (Relay)
|
Three SPDT relats
|
|
Dimensions
|
3 3/4″ x 3 3/4″ x 5 13/16″
|
|
Control type
|
On/Off
|
|
Password protection
|
yes
|
|
Display
|
Graphic LCD
|
|
Power
|
115 to 230 VAC 50/60 Hz
|
|
Housing
|
1/4-DIN
|
|
CE Compliance
|
Yes
|
|
Brand
|
Cole-Parmer
|
隔离和可逆的4至20 mA输出允许比例输出！
测量显示清晰，图形LCD背光
方便的单点校准
密码保护，确保系统的安全性
电导率范围0.000至300,000μS
接受探头，0.01，0.1，1.0，10细胞中的常量2 – 线或4线设计
RS-485输出用于远程访问允许多个单元的控制，从您的电脑
科尔-帕默在线控制器提供更昂贵的机型的功能。图形液晶背 光，同时显示测量，温度，电导池常数，温度系数，继电器状态和发射器的电流输出。校准数据存储在存储器中，使得单元可以进行测量。用户可选择的细胞常数，参考温度和温度系数和温度自动补偿，保证测量精度。密码保护，RS-485进行远程访问，孤立的和可逆的4至20 mA输出提供了扩展的数据安全选项。一个10K的热敏电阻导电与兼容cells.Cond 500（05802-06）控制器有一个孤立的和可逆的4 20 mA输出和可编程开/关继电器：两个导电性和温度-高/低控制的理想选择三套激活报警，泵或其他设备。
